Technical Notice CSO
/CPO V1.1 / 10.14
4 CPO 310 - CSO 300 models
4.1.2
Rear view
Fig. 4-2 : CPO 310 type chiller - (rear view)
(5)
Cooling liquid outlet
(6)
Electric power connecto
r
(7)
Cooling liquid re
turn inlet
(5)
(6)
(7)
19
21
