Marksa CSO Series - 9.7 Hot Gas Bypass (G)

Page 54 / 86 Technical Notice CSO/CPO V1.1 / 10.14
9 Options
9.1.7 Hot gas bypass (G)
9.1.7.1 Description of the option
The hot gas bypass (1) option makes it possible to precisely maintain the liquid temperature by elimi-
nating disruptive starting up and powering down of the compressor.
Precision on the order of ± 0.1°C is possible with the addition of an Omron thermostat.
Fig. 9-6 : Basic schematic
(1) Hot gas bypass
(1)
