Marksman M5A - Step 2: 10-Pin Main Harness Installation

First Vacant Socket: (For Use with ALA-RPT Relay Pack Only)
See Optional Accessory Connection for proper wiring.
Gray Wire: (Pulsed Ground for Car Horn)
Connect the gray wire to the negative trigger wire on the vehicle’s horn relay.
Warning! Maximum output of this wire is 300mA. Horn systems requiring positive voltage or
more than 300mA to trigger the horn relay will require an additional relay to increase current
capabilities.
Blue Wire with White Stripe: (Channel #3 Output)
Connect the blue/white wire to the device that will be operated from Channel #3 of the alarm
system. The blue/white wire has a “maximum” current capacity of 300mA.
Brown Wire: (Siren + Output)
Connect the brown wire to the positive wire from the siren. Ground the remaining wire from the
siren for proper operation.
Blue Wire: (Optional Negative Sensor Input)
The blue wire is an instant grounding trigger input for optional hood/trunk grounded pin switches
or any electronic sensor.
Green Wire: (Negative Door Pin Switch Input)
The green wire connects to the common wire of the vehicle that switches on the dome light.
Violet Wire: (Positive Door Pin Switch Input)
The violet wire connects to the common wire of the vehicle that switches on the dome light.
Second Vacant Socket: The second vacant wire socket provides a 1 second pulsed ground
(300mA) output when Channel #2 is activated (See Optional Accessory Connections).
Red/White: (Pulsed Parking Light Relay Output + or – Selectable)
The “Red/White” wire has already been assembled to work with a +12 volt switched parking light
system (most vehicles). For vehicles with ground switched parking light activation cut this wire
and connect it to ground.
Pink: (Parking Light Relay Input)
The pink wire is the input to the flashing parking light relay. The connection of the pink wire will
determine the output polarity of the flashing parking light relay. Connect the pink wire to (+)
battery to have (+) output from the relay or connect the pink wire to chassis ground to have
negative output from the relay.
Step 2: 10-Pin Main Harness Installation
