MGT 240M–1200M 3” NXT2 - SYSTEM 14 DEMAND
SYSTEM INFORMATION
6
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
A A
B B
C C
D D
DATE
FRAC.
DRN.
APP'D.
DEC.
DRAWING NO.
SCALE
FILE ID.
SHEET
REV.
OF
MGT QUAD PARALLEL WATER SOFTENER (3900 VALVE)
GENERAL ARRANGEMENT
MGT QUAD PAR 3900
11AJJG
3/4/2009
REVISIONS
NO. BY REMARKSDATE
BRINE TANK
BT DIAMETER
RESIN TANK
RT DIAMETER
RESIN TANK
RT DIAMETER
RESIN TANK
RT DIAMETER
RESIN TANK
RT DIAMETER
RAW WATER INLET
30-100 PSI
SOFTENED
WATER OUTLET
2" DRAIN
RT=_______
BT=_______
DIMENSION TABLE
L=_______
W=_______
H=_______
MGT-_____________
NOTES:
ALL PIPING, FITTINGS, ETC SHOWN WITH DASHED LINES
ARE PROVIDED BY OTHERS.
GENERAL PLUMBING CONNECTIONS ARE SHOWN FOR
CLARITY ONLY.
BY-PASS VALVE
(NORMALLY CLOSED)
3" INLET
ISOLATION VALVE
3" FLECK 3900
CONTROL VALVE
H
L
W
BRINE LINE
TUBING
FLOW SENSOR
3" OUTLET
ISOLATION VALVE
LAYOUT DRAWING - QUAD DEMAND SYSTEM
