MGT 240M–1200M 3” NXT2 - SYSTEM 14 DEMAND
INSTALLATION
15
NETWORK TIMER SYSTEM CONFIGURATION WIRING
Network Timer System Configuration Wiring Diagrams
System 14 Twin
System 14 Triple Parallel
CAT 5 CABLE
UNIT 1 UNIT 2
UNIT 1 UNIT 2 UNIT 3
UNIT 1 UNIT 2 UNIT 3 UNIT 4
CAT 5 CABLE
CAT 5 CABLE
CAT 5 CABLE CAT 5 CABLECAT 5 CABLE
System 14 Quad Parallel
