MGT 240M–1200M 3” NXT2 - SYSTEM 14 DEMAND
SYSTEM INFORMATION
7
DIMENSION CHART
MODEL
INLET SIZE
(Inches)
TANK SIZE LENGTH
WIDTH
(Inches)
HEIGHT*
(Inches)
SOFTENER
(Inches)
BRINE
(Inches)
TWIN
(Inches)
TRIPLE
(Inches)
QUAD
(Inches)
240 3 24x72 24x50 89 121 153 24 95
300 3 24x72 24x50 89 121 153 24 95
450 3 30x72 30x50 115 153 191 30 93
600 3 36x72 39x60 129 173 217 39 94
900 3 42x72 42x60 143 208 273 42 113
1200 3 48x72 42x60 155 211 267 48 113
*Leave a minimum 24 inch clearance to the height of the unit for loading media.
Dimensions are for general arrangement use only.
