MGT 240M–1200M 3” NXT2 - SYSTEM 14 DEMAND
OPERATION
28
MASTER PROGRAMMING -
PROGRESSIVE FLOW (SYSTEM 14)
STEP FACTORY SETTING RANGE
SETTINGS REVIEW OFF On-Off
LANGUAGE ENGLISH
English, Francais, Deutsch, Italiano, Espanol,
Nederlands, Portugues
ASSISTANCE NAME 1 ENTERED BY DEALER
ASSISTANCE NAME 2 ENTERED BY DEALER
ASSISTANCE PHONE ENTERED BY DEALER
SYSTEM System 14 (2-8 Units) Demand
R
System 4 (Single Unit)
System 5 (2-8 Units) Parallel Interlock
System 6 (2-8 Units) Parallel Series Regeneration
System 7 (2 Units) Alternating (I)
System 8 (2 Units) Alternating (D)
System 9 (2-8 Units) Alternating with Stanby Uni
System 14 (2-8 Units) Demand Recall
NUMBER OF TANKS 2-8
2 thru 8
TRIP POINT #1 - GPM see data table*
1-9999
TRIP POINT #1
-
SERVICE
DURATION
3
1 S
1-90 seconds
TRIP POINT #1
-
STANDBY
DURATION
4
60 S
60 - 300 seconds
TRIP POINT #2, #3, etc
as needed
VALVE 2900
2815, 2510, 2750, 2850, 2900, 3150, 3900
REGEN. FLOW Downflow
Filter
Downflow
UNITS US
US, Metric
CAPACITY - GRAINS* see data table* 0-9,999,999 Grains
HARDNESS - GPG ENTERED BY DEALER
0-199 gpg
REMOTE REGENERATION Off
Off
Delayed
Immediate
DAY OVERRIDE/TIME DRIVEN 7
Off - 99 Days
REGEN. TIME 02:00AM
Any Time
LOCK WINDOW #1 Off
Off, On
LOCK WINDOW #2 Off
Off, On
BACKWASH 10 M
0-240 Mins
DRAW 60 M
0-240 Mins
RAPID RINSE 10 M
0-240 Mins
REFILL* see data table*
0-240 Mins
PAUSE 0 M
0-240 Mins
METER TYPE* see data table*
Generic
Paddle (0.75", 1.00", 1.50", 2.00", 3.00")
Turbine (0.75", 1.00", 1.25", 1.50")
CONTINUOUS FLOW DETECT Off
On, Off
AUXILIARY 1 Off
Standby, Off, Alarm Based, Cycle Based, Time Based,
Volume Based
AUXILIARY 2 Off
Standby, Off, Alarm Based, Cycle Based, Time Based,
Volume Based
PUSH SETTINGS
1
On
On, Off
SAVE AS NON-FACTORY
2
On
On, Off
LOCK SETTINGS Off
Time Based, Off, Delayed, Enter Code
* For settings with an asterisk, consult the data table on page 5.
1
Use PUSH SETTINGS to push the programming settings to the other unit. You only have
to program one unit.
2
Use "SAVE AS NON-FACTORY" to save all the programmed settings. When resetting
the board, you can choose to reset to factory default settings or the non-factory settings.
3
Trip Point - Service Duration is how long the service flow is over the trip point before an additional unit is brought online.
4
Trip Point - Standby Duration is how long the service flow is under the trip point before a unit brought offline.
