TECHNICAL INFORMATION
SOUND SPECIFICATION
• ACTIVE STEREO LOUDSPEAKER WITH BASS REFLEX SYSTEM
• BASS AND TREBLE TONE CONTROLS
• CLASS D AMPLIFIER: 2X8W+1X25W
• WOOFER: 1X 4”
• TWEETER: 2X 3/4”, FERROFLUID COOLED
• MAX SPL: 100DB SPL @ 1M
(GROUND PLANE 300HZ, 1%THD)
• FREQUENCY RANGE: 50- 20.000HZ
• CROSSOVER FREQUENCY: 4200HZ
CONNECTIVITY
• BLUETOOTH: STANDARD V4.0 + EDR
• INPUT 1 - 3.5MM: 1X
TECHNICAL INFORMATION
• MAINS INPUT VOLTAGE: 100-240VAC/70W
• ABSOLUTE MIN/MAX: 90-264VAC
• MAINS FREQUENCY: 50-60Hz
• MAX PEAK POWER CONSUMPTION: 70W
• TWO STANDBY MODES: POWERSAVER MODE (0,40W)
AND STANDARD MODE (3,5W)
• MAX POWER OUTPUT: 50W RMS
• WEIGHT: 3.00KG
• SIZE: 265 X 160 X 150MM
NOTE: THE FRONT FRET IS NOT REMOVEABLE. THIS ILLUSTRATION INTENDS TO
SHOW THE INTERNAL SPEAKER LAYOUT. DO NOT ATTEMPT TO REMOVE THE
FRONT FRET FOR RISK OF DAMAGING YOUR ACTIVE LOUDSPEAKER.
