Manual Blue 0 ~ C ~ 128
Adjustable when the
white balance mode is
Picture effect
1. Off
2. Neg
Sharpness 0 ~ A ~ 14
2D NR
1. Off
2. 1
3. 2
3D NR
1. Off
2. LOW
3. Typ
Image Mode
1. Default
2. Custom
The user may customize
his/her desired image
Image Mode
Load
ENTER
Adjustable when the
Image mode is set to
Custom. After selected,
the corresponding
Image mode
parameters will be read
Brightness 0 ~ A ~ 15
Adjustable when the
Image mode is set to
Hue 0 ~ A ~ 15
Adjustable when the
Image mode is set to
Saturation 0 ~ A ~ 15
Adjustable when the
Image mode is set to
Gamma 0 ~ A ~ 3
Adjustable when the
Image mode is set to
Pan Tilt
Pan/Tilt Limit On / Off
Turn on/off the angle
27
Pan Right Limit 0 ~ 170 Limit the right angle
Pan Left Limit -170 ~ 0 Limit the left angle
Tilt UP Limit 0 ~ 90 Limit the upward angle
Tilt Down Limit -30 ~ 0
Limit the downward
Pan Flip On / Off
Activate the reverse Pan
Tilt Flip On / Off
Activate the reverse Tilt
Preset Speed
1. 5 deg/sec
2. 25 deg/sec
3. 50 deg/sec
4. 80 deg/sec
5. 120 deg/sec
6. 160 deg/sec
7. 200 deg/sec
Set the rotation speed of
the cradle head when
Preset is executed
PTZ Speed
Comp
On / Off
Set the Pan/Tilt moving
speed to vary from the
D-Effect Mirror
1. Off
2. MIRROR
3. Flip
Set the mode at which
the image is mirror or
flipped
Auto Focus
AF Sensitivity
1. LOW
2. Middle
For AF triggering speed,
the higher the speed is,
the faster AF is triggered
AF Frame
1. Center Area
2. Full Area
3. Auto
AF frame setting, when
central area was set as
AF frame, focusing will
be on the center of the
screen. When Full
Frame was set as AF
frame, focusing will be
calculated based on the
CV730 Manual
www.marshall-usa.com25 26
