Marshall Amplification CV730 User Manual

38
6.2.4 Setting - System Setting
No
Item
Function Descriptions
1 Resolution
Set the resolution of the camera, resolutions supported by the camera
are as follows:
3840 x 2160 59.94 / 50 / 29.97 / 25 fps
1080P 59.94 / 50 / 29.97 / 25 fps
720P 59.94 / 50 / 29.97 / 25 fps
After switching to the resolution, the camera will restart. Please refresh
the browser
2
Apply
After the setting has been modified, select this button to apply the
setting
1
2
3
39
6.2.5 Setting - Video
No Item Function Descriptions
1 Camera name
Modify the camera name
 Camera names are limited to 1 - 12 characters
 Please use a camera name by mixing uppercase and lowercase
letters or numbers. Do not use “/” and “space” or special symbols
2 Camera Location
Modify the location of the camera, such as Meeting Room 1
 Camera location is limited to 1 - 12 characters
 Please use a camera name by mixing uppercase and lowercase
letters or numbers. Do not use “/” and “space” or special symbols
3
Streaming 1/Streaming
2/Streaming 3
CV730 supports 3 streaming outputs. Please refer to 6.2.5.1
Streaming Parameter Setting for relevant settings
4
Open Streaming
Confirm whether or not the streaming function is opened
5 Force I Frame
Check this item to insert IDR frame into specified series flow and apply
its setting. User’s setting will be reserved and displayed in GUI
interface
6.2.5.1 Streaming parameter setting
Function Streaming 1 Streaming 2 Streaming 3
Encode Format H.265 H.264
Resolution 4K /1080P / 720P 1080P/720P 640 x 360
Frame Rate Setting according to the supported resolution
Bit Rate (kbps)
Range 2,000 ~ 20,000 2,000 ~ 20,000 512 ~ 5,000
Factory
Default
7,000 7,000 1,000
Rate Control CBR / VBR
IP Ratio Setting according to the supported resolution
1
2
3
4
5
1
2
1
2
3
4
5
CV730
CV730
CV730 Manual
www.marshall-usa.com37 38
