Maruyama B230L - Safety and Instruction Decals; Product Description

— US-9 —
Safety and Instruction Decals
Safety decals and instructions are easily visible to the operator and are located near any area of
potential danger. Replace any decal that is damaged or lost.
ON SHAFT
(Part No.221501)
ON SHAFT
(Part No.221502)
Product Description
B230L/B270L/B270L TURBO/
B300L/B300L TURBO
1. Gearcase
2. Shaft Assembly
3. Model Name
4. Saferty Decal
5. Loop handle
6. Throttle Trigger and Stop Switch
7. Shaft Grip
8. Clutch Drum Housing
9. Engine
10. Serial Number (on side of engine)
11. Air Filter
12. Fuel Tank
13. Throttle Cable and Stop Switch Wires
14. Debris Shield
15. Trimmer head
11
7
8
6
5
4
3
2
1
12
13
14
15
9
10
