— US-14 —
5. After the engine starts, squeeze and release the
throttle trigger to return it to the idle position, then
move the choke lever to the open (
) position.
If the engine stops running before you move the
choke lever to the open (
) position:
Go ahead and open the choke, pull the starter grip with
the throttle trigger positioned at Fast-idle position.
Hot Restart
To start an engine that is already warmed up (hot restart),
or if the ambient temperature exceeds 68°F (20°C):
1. Pump the primer bulb at the bottom of the carbu-
retor until fuel can be seen flowing through the
fuel return line to the fuel tank.
(Flowing fuel should be almost clear, not foamy
or full of bubbles.)
2. Move the choke lever to the open (
) position.
3. Leave the throttle trigger in the idle position and
pull the starter grip.
4. If the engine fails to start after three to four pulls,
follow the instruction in the Cold Starting
Procedure section (US-13).
If the engine fails to start after you follow the
above procedures, contact an authorized
MARUYAMA dealer.
To Stop The Engine:
1. Release the throttle lever.
2. Push the stop switch of the throttle trigger until
the engine will stop.
Fast-idle lock button
Stop Switch
WARNING
POTENTIAL HAZARD
• The components of your recoilstarter
assembly are under high spring tension. If
improperly disassembled these parts may
-
strike you with considerable force, possi-
bly causing personal injury.
W
HAT CAN HAPPEN
• Contact with the parts can cause severe
personal injury.
HOW TO AVOID THE HAZARD
•
Never attempt to disassemble your
recoil starter assembly yourself.
Always consult your authorized
MARUYAMA dealer for repair by
qualified service technicians.
CAUTION
• Do not pull the Starter rope all the way
out.
Control Lever
Throttle Lever
Throttle Trigger
L:
Low speed
H:
High speed
