_
10
_
WARNING
POTENTIAL HAZARD
Without the shoulder strap/ harness installed on the Trimmer/ Brushcutter, the blade can
produce side thrust which can expose the operator and bystanders to blade contact.
WHAT CAN HAPPEN
Contact with Brushcutter blade can cause severe personal injury.
HOW TO AVOID THE HAZARD
Never operate the Trimmer/ Brushcutter without installing and using the shoulder strap/
harness .
Snap the Hook into the ring on the drive shaft. To detach the shoulder strap/ harness quickly from the
Trimmer/ Brushcutter, pull upward on the Red Band/ Tab.
Attaching Shoulder Strap/ Harness
[BC2301RS, BC2601RS, BC3021RS] [BC4321H-RS]
Red Band
Red Tab
Shoulder Harness
Shoulder Strap
Hook
Hook
Ring
Ring
Pull
Pull
