Signal Description
Pin Description
B3 A49 125 RXD[3] O, Z Serial MAC interface Copper Link Status[1]
connection.
1 = Copper link up
0 = Copper link down
C3 A50 126 RXD[2] O, Z Serial MAC interface Copper Link Status[0]
connection.
1 = Copper link down
0 = Copper link up
D3 B43 128 RXD[1] O, Z Serial MAC interface PHY_SIGDET[1] con-
nection.
1 = S_OUT± valid code groups according to
clause 36.
0 = S_OUT± invalid
B2 A51 3 RXD[0] O, Z Serial MAC interface PHY_SIGDET[0] con-
nection.
1 = S_OUT± invalid
0 = S_OUT± valid code groups according to
clause 36
Table 7: 1.25 GHz Serial High Speed Interface (Continued)
117-TFBGA
Pin #
96-aQFN
Pin #
128-PQFP
Pin #
Pin Name Pin
Type
Description
