Masibus 409-W User Manual

Strain Guage Indicator: 409-W
REF NO: m59A/om/501
Issue NO: 03
Page 11 of 34
(brHt)
10 to 100
F-CNT
(F-CNT)
Filter count
IIR Filter is apply for sated count only.
0-500
20
ALPHA
(ALPHA)
Alpha
Set alpha for IIR Filter.
0-100
0
M-CNT
(M-CNT)
Average Count
Moving Average Filter is apply for sated count only.
0-500
20
PASS
(pass)
Password
Set Device Password
0 to 9999
1
CAL**
Calibration
CALIB
(CALIB)
Calibration
methods
Set calibration method.
0 : S-WGT (Sample weight calibration method)
1 : TH-mV (theoretical mV calibration method)
S - W G T
RESO
(RESO)
Resolution
Set position of Decimal Point on Display.
0 : 0
1 : .0
2 : .00
3 : .000
4 : .0000
.00
1
ZERO
(zero)
Zero
Can be set to any value within the Input Range & less the
SPAN Value.
0.00
SPAN
(span)
Span
Can be set to any value within the Input Range & greater
the ZERO Value.
200.00
2
mV-FS
(mv-FS)
Full span mV
Can be set to any value within the input mV range.
20.000
2
CALZ
(CALZ)
Calibrate zero
theory mV
Set above calibration parameters as per requirement
Press DOWN key to calibrate ZERO
Process
value
1
SMP-W
(SMP-W)
Sample weight
calibration
Set above calibration parameters as per requirement,
Press DOWN key to calibrate ZERO
press UP key to calibrate SPAN
Process
value
Table 6.1
1
Display only if method is S-WGT.
2
Display only if method is th-mV.
Note 1: For SGI input DI is used to Tare the weight. When 24V Signal is applied
momentarily at the DI terminal, it will tare the weight.
