Masibus 409-W User Manual

Strain Guage Indicator: 409-W
REF NO: m59A/om/501
Issue NO: 03
Page 8 of 34
6. Configuration Guidelines
6.1 Menu Parameter List
Display
Name
Description
Default
Value
RESO
(RESO)
Resolution
Set position of Decimal Point on Display.
0 : 0
1 : .0
2 : .00
3 : .000
4 : .0000
.0
MAXMV*
(MAXMV)
Maximum Mv
range
Set mV range for resolution.
0: 15mV
1 : 30mV
2 : 75mV
3 0 m V
OFST
(OFST)
Offset
Set offset value for weight
-9999 to 9999
0 . 0
KTARE
(KTARE)
Keypad Tare
option
Set value to enable or disable Key tare
0: Disb
1: En
eN
ZTARE
(ZTARE)
Zero Tare
set to clear Tare
0: NO
1: YES
NO
STEP
(STEP)
Step value
Set steps for display increment
0: OFF
1: 2
2: 5
3: 10
O F F
Rtr
Retransmission
RET V
(rETV)
Retransmission
voltage
Retransmission Output Type
This output is according to PV input.
Zero & Span acts as Min & Max value of retransmission o/p
scale respectively.
0 : 0-10V
1 : 0-5V
2 : 1-5V
Voltage or Current is Jumper Selectable from the
Hardware.
0-10
