Masibus 409-W User Manual

Strain Guage Indicator: 409-W
REF NO: m59A/om/501
Issue NO: 03
Page 9 of 34
RETmA
(rEtma)
Retransmission
current
Retransmission Output Type
This output is according to PV input.
Zero & Span acts as Min & Max value of retransmission o/p
scale respectively.
0 : 4-20mA
1 : 0-20mA
Voltage or Current is Jumper Selectable from the
Hardware.
4-20mA
OPZ
(OP Z)
Output Zero
Set output zero for retransmission scaling
0.0
OP S
(OP S)
Output Span
Set output span for retransmission scaling
200.0
R MAPP
(R MAPP)
RET map
Set value for retransmission mapping
0: NET
1: Gross
0
Alarm
Alarm Logic
ATYP
(ATYP)
Alarm Type
Set which Set Point to shown in SV display in RUN mode
while device is in Auto Mode
0 : HH
1 : HL
2 : LL
LL
SEL
(SEL)
Selection for Alarm 1 & 2.
0: AL1
1: AL2
-
Al1/AL2
(AL1/AL2)
Alarm 1/Alarm 2
Set which Set Point to shown in SV display in RUN mode
while device is in Auto Mode
0 : ALRM
1 : TRIP
A L R M
LACH
(LACH)
Latch
Enable or Disable Latch
0 : YES
1 : NO
NO
HYST
(HYST)
Hysteresis
Hysteresis Value for Relay 0.000 to 0.255
1 to 255
Resolution = 0
0.1 to 25.5
Resolution = 0.0
0.01 to 2.55
Resolution = 0.00
0.1
