Masibus 409-W User Manual

Strain Guage Indicator: 409-W
REF NO: m59A/om/501
Issue NO: 03
Page 10 of 34
0.001 to 0.255
Resolution = 0.000
0.0001 to 0.0255
Resolution = 0.0000
OPES
(opes)
OPEN Sensor
Status
Set Control O/P & Retransmission state when Input OPEN
condition.
0 : UP
1 : DOWN
UP
ST-1
(st-1)
Set Point 1
Range Depending on PV sensor type selected
1 0 . 0
ST-2
(st-2)
Set Point 2
Range Depending on PV sensor type selected
1 0 . 0
RDLY
(rdLY)
Relay Delay
(For Relay)
Relay Delay is amount of time (in sec), that Relay will wait
before getting ON after the ON condition occurs.
0 to 9999 sec
0 s e c
CTRl
(CTRL)
Control Relay
Select Control Relay Status
0 : ON
1 : OFF
O F F
COM
Communication
SRNO
(srno)
Serial No
Unit ID for Modbus-RS485 Communication
1 to 247
1
BAUD
(baud)
Baud Rate
Set Modbus RS485 Communication Baud Rate
0 : 4800 (4800 bps)
1 : 9600 (9600 bps)
2 : 19.2K (19200bps)
3 : 38.4K (38400bps)
9600
PRST
(PRST)
Parity/Stop bit
Set Parity and Stop bit
0 : PNS1
1 : PNS2
2 : POS1
3 : POS2
4 : PES1
5 : PES2
PnS1
FLTR
(fltr)
Filter
Filter is time (in sec), that PV will wait before getting to its
value after filter set.
0-60 sec
0
BRHT
Brightness
Adjust Brightness of the 7-segment Display.
100
