Masport Inbuilt Gas Fires - 15 - 19/11/04
PICCOLO - FAN
The fan operates by using the rocker switch on the left-
hand side of the fascia. To adjust the desired fan
speed, operate the rocker switch. The fan has 2
speeds, a high speed for more rapid air movement and
a low speed. The fan should not be used until the fire is
up to operating temperature, approximately 10mins.
The fan can be left running after the fire has been shut
down until it is circulating no more useful heat.
PICCOLO- SHUT DOWN
1) Push the knob in momentarily and rotate clockwise
to the pilot position. To extinguish the pilot, push
the knob in and turn clockwise to the “OFF”
position. Do not force.
2) Disconnect all electric power and gas to the
appliance if service is to be performed.
EIS MODELS-LIGHTING
Ensure that the gas supply valve is ON and the mains
power is switched ON.
1) Turn on the top switch at the left side of the fascia.
2) Provided that there is a jumper wire across the
thermostat terminals on the control box (inside the
lower grille), or that the thermostat (if connected) is
calling for heat, there will be a continuous spark at
the igniter terminals after about five seconds.
3) If the spark does not appear, switch OFF the top
switch (to re-set the ignition module), and switch it
ON again.
4) If the spark appears but there is no gas available,
the spark will cease after about ten seconds,
bringing the ignition sequence to a halt.
Recommence the sequence by switching OFF and
ON once again.
5) Repeat as necessary until air is cleared from the
pipeline and the burner lights. When this happens,
the spark will automatically cease.
6) The flame height can be controlled with the middle
rocker switch on the LH side of the fascia. Note
that flame size only changes between high and
low.
7) While the fan speed can be pre-selected at this
time, using the lower rocker switch, the fan will not
start until the firebox has reached a reasonable
working temperature. The fan will start
automatically once this has been attained. (Usually
about 10 minutes, on full flame height).
EIS – FAN
The fan operates by using the bottom of the 3 rocker
switches on the left-hand side of the fascia. To select
the desired fan speed, operate the rocker switch. The
fan has 2 speeds, a high speed for more rapid air
movement and a low speed.
EIS models are fitted with a thermodisc fan control.
This means the fan will operate only when the heater is
up to operating temperature (approximately 10 minutes
from start on high burn) and will stop automatically
once the heater has cooled down. This is particularly
useful when a thermostat is fitted, as the fan will not be
running unnecessarily. Because the thermodisc is
fitted, it is not necessary to operate the switch on the
fascia. It can be kept permanently on at the desired
speed setting. The fascia switch overrides the
thermodisc if it is set in the central “off” position.
EIS-SHUTDOWN
1) Use the top rocker switch to turn off the main
burner.
2) Use the bottom rocker switch, if desired to turn off
the fan immediately. If not manually switched off
the fan will automatically turn off once the
appliance has cooled to a point where no more
useful heat can be produced.
3) Disconnect all electric power and gas to the
appliance if service is to be performed.
ECS II MODELS – OPERATING
NOTE: Full instructions covering the capabilities
of this system are detailed in a separate leaflet.
Only basic instructions for MANUAL operation are
given here.
CAUTION. To avoid the risk of backburning, do not
attempt to re-light the fire less than three minutes after
it has been extinguished.
ECS II models have an RF control system which does
not require the remote to be aimed directly at the
heater. They have a handpiece which incorporates the
thermostat. If there is no display on the handpiece
panel, check the batteries (2 AAA alkaline). When
switched OFF, the display will show the day of the
week, the time, the room temperature and OFF. See
the leaflet for setting the correct day and time.
NOTE. Before using the remote, you must ‘teach’ the
control system to recognise only your particular
handpiece.
• Set the remote to OFF by pressing the ON/OFF
button if necessary. (OFF will be displayed).
• Turn OFF the mains supply to the heater.
