89
SPECIFICATIONS
MODEL 500UEJ 600UEJ 800UEJ
Dimensions:
Overall length 2730 mm (107.5in)
Overall width 1460mm (57.5in)
Overall height 1880mm (74.0in)
Seat height 870mm (34.3in)
Wheelbase 1840mm （72.4in）
Minimum ground clearance 330mm （13.0in）
Minimum turning radius 5000mm (196.9in)
Maximum speed 70 km/h ≥85 km/h
Basic weight:
Mass of whole equipments (Not include
driver)
640kg
Engine:
Engine type 500cc: CF188-B 600cc: 196S-B
800cc: 2V91MW
Cylinder arrangement 500cc/600cc: Single cylinder 800cc: Two cylinder
Displacement 493 ml 594 ml 800 ml
Bore × stroke 500cc/600cc: 87.5×82.0 mm(3.4×3.2 in)
800cc: 91×61.5 mm (3.58×2.42 in)
