Mastech MS2001 User Manual

2.
3.
Set the rotary switch at “ ” position.
Connect the red test lead to the anode of the diode to be
tested and the black test lead to the cathode of the diode.
The approx. forward voltage drop of the diode will be
displayed. If the connection is reversed ， only figure “1” will be
shown.
SPECIFICATIONS
Accuracy is specified for a period of one year after calibration and
at 18 ℃ to 28 ℃ (64°F to 82°F) with relative humidity to 80%.
GENERAL
Maximum voltage
between terminals and
earth ground
: CAT II 1000V and CAT III 600V
Display : LCD, 1999 counts, updates 2 ― 3/ sec.
Polarity indication : “ ― ”displayed for negative polarity.
Overrange Indication : Only figure “1” on the display.
Jaw opening capability
: 42mm (Max conductor size)
Power : 9V battery, NEDA 1604 6F22 006P.
Low battery indication : “ ” Appears on the display.
Operating Environment
: 0 to 40 ℃
Storage temperature : ― 10 ℃ to 50 ℃
Temperature coefficient
: 0.1 × specified accuracy) / ℃
( <18 ℃ or >28 ℃ )
Altitude : 2000m
Size : 250mm × 99mm × 43mm
Weight : Approx.460g.
-8-
