09
10
2: When inputting voltage on the meter input terminal,
due to the existence of the induced voltage, voltage
induction indicator also may light.
3: Interference sources of external environment (such
as flashlight, motor, etc.) may trigger non-contact
voltage detection by mistake.
Technical Data
General characteristics: the maximum voltage of
voltage input end and ground CAT III 600V and
600V~
Display method: LCD display with maximum of 1999
Measuring principle: double integral A/D convertion
Measuring range choice: Automatic
Measurement speed: 3 times/s
Unit display: has function and power unit symbol
display Polarity indication: display “-” symbol for
negative polarity input
Overrange display: “OL”
Data hold function: display “ ” on the top of LCD
Low battery display: display “ ” on the top of LCD
Power battery: DC1.5V Х3 SIZE AAA.
Outside measurement: 220mm×81mm×41mm
Weight: about 286g (include battery)
The largest size of open clamp jaw: 26mm
Operating environment: 5°C~35°C
Storage temperature: -10°C~50°C
H
Accuracy Indicators
Accuracy: ±(% of reading + digits) with one year of
warranty Environment temperature: 18°C~28°C
Environment humidity: not more than 75%
Temperature coefficient: 0.1 × Accuracy/ 1°C
* When measuring AC current,
place the conductor to
be measured be in the center
position of clamp head.
If it is not in the center
position, it can increase
error by 1.5%
DC Voltage
1mV
10mV
±(0.6% of reading + 3 digits)
200mV
2V
20V
600V
0.1mV
1V
±(0.8% of reading + 3 digits)
Measuring
range
Resolution
Accuracy
200V 0.1V
Input impedance: 10MΩ.
Maximum allowable input voltage: 600V DC or 600V
AC (RMS)
Sign
Condctor
Sign
Sign
MULTIFUNCTION DIGITAL MULTIFUNCTION DIGITAL
