Mastech ms8217 User Manual

31 32
4 TECHNICAL SPECIFICATIONS
4.1 General specifications
• Environment conditions:
1000V CAT II and 600V CAT III
Pollution degree: 2
Altitude < 2000m
Operating temperature: 0~40°C, 32°F~122°F(<80% RH,
<10°C non-condensing)
Storage temperature: -10~60 °C, 14°F~140°F(<70% RH,
battery removed)
• Temperature Coefficient: 0.1(specified accuracy) / °C
(<18°C or >28°C)
• MAX. Voltage between terminals and earth
ground: 1000V AC rms or 1000V DC.
• Fuse Protection: µA and mA: F 500mA/250V Ø5x20;
A: F 10A/250V Ø6.3x32.
• Sample Rate: 3 times/sec for digital data.
• Display: 3 3/4 digits LCD display. Automatic indication
of functions and symbols.
• Range selection: automatic and manual.
• Over Range indication: LCD will display "OL".
• Low Battery Indication:The is displayed when the
battery is under the proper operation range.
• Polarity indication: "-" displayed automatically.
• Power source: 4.5V
• Battery type: AAA 1.5V.
• Dimensions: 185(L)87(W)53(H) mm.
• Weight: 360g. Approx. (battery included).
4.2 Measurement specifications
Accuracy is specified for one year after calibration, at
operating temperatures of 18 °C to 28 °C, with relative
humidity at 0% to 75%.
Accuracy specifications take the form of: ±(% of
Reading + Number of Least Significant Digits)
4V
40V
400V
10mV
1mV
100mV
400mV 0.1mV
- Overload protection: 1000V DC or AC rms
- Frequency Range: 40Hz~500Hz
- Manual Range only
±(0.5% reading + 3dgt)
Measuring Range
Resolution
Accuracy
4.2.1 DC Voltage
1000V
1V
±(1.0% reading + 3dgt)
Measuring Range
Resolution
Accuracy
4.2.2 AC Voltage
±(3.0% reading + 3dgt)
±(1.0% reading + 10dgt)
4V
40V
400V
10mV
1mV
100mV
400mV 0.1mV
1000V
1V
- Overload protection: 1000V DC or AC rms
- Frequency Range: 40Hz~500Hz
- Manual Range only
DIG ITAL MU LTI MET ER DIG ITAL MU LTI MET ER
