multi-function socket ）
10A
Input for 200mA to 10A current
measurements. (Receiving the red test
lead)
2.5 Accessories
Delivered with the multimeter:
( User's manual One piece
(
Test
leads One piece
( Carry case One piece
( "K" type bead
Thermocouple
One piece
( Special Multi-function
socket
One piece
3. FUNCTION DESCRIPTION
3.1 General Functions
3.1.1
DATA
HOLD mode
Data Hold mode makes the meter stop updating the display. Data Hold function can be cancelled by
changing the measurement mode, or push HOLD key again.
To
enter and exit the Data Hold mode:
1. Press HOLD key. Fixes the display on the current value, is displayed.
2.
A
second short press returns the meter to normal mode.
3.1.2 Battery Saver
Turn on the meter. And then The Meter will be turned off automatic after approx. 30 minutes.
3.2 Measurement Functions
3.2.1 AC and DC Voltage measurement
To
avoid electrical shock and/or damage to
the instrument, do not attempt to take any
voltage measurement that might exceeds
1000Vdc or 750Vac rms.
To
avoid electrical shock and/or damage to
the instrument, do not apply more than
1000Vdc or 750Vac rms between the
common terminal and the earth ground.
Voltage is the difference in electrical potential between two points.
The polarity of ac (alternating current) voltage varies over time; the polarity of dc (direct current) voltage
is constant.
The Meter's DC voltage ranges are 200.0mV, 2.000V, 20.00V, 200.0V and 1000V ； AC voltage ranges are
2.000V, 20.00V, 200.0V and 7500V.
To
measure ac or dc voltage:
1. Set rotary switch to the proper range.
2. Connect the black and red test leads to the COM and V terminals respectively.
