Mastech MS8264 - Audible Continuity; Transistor; Temperature; Capacitance

forward voltage of diode
Forward DC Current: approx. 1mA
Reversed DC Voltage: approx. 2.8V
Overload protection: 380Vdc or 380Vac rms.
4.2.6 Audible continuity
Rang
e
Continuity beeper
≤ 30 (
Open circuit voltage: Less than 700mV.
Overload protection: 380Vdc or 380Vac rms.
4.2.7 Transistor
Ran
ge
Description Test Condition
hFE
Display read
approx. HFE value
(0-1000) of
transistor under
test (all type).
Base Current
approx. 10 μ A,
Vce approx. 2.8V.
4.2.8 Temperature
Range Resoluti
on
Accuracy
-20 ℃ ~0 ℃
1 ℃
± (5.0% of rdg+4
digits)
1 ℃ ~400 ℃ ± (1.0% of rdg+3
digits)
401 ℃ ~1000
℃
± 2.0% of rdg
Overload protection: Resettable fuse (F200mA/250V).
* Temperature specifications do not include thermocouple errors.
4.2.9 Capacitance
Range Resolutio
n
Accuracy
2nF 1pF
± (4.0% of rdg+3 digits)
20nF 10pF
200nF 0.1nF
2 ( F 1nF
20 ( F 10nF
Overload protection: Resettable fuse (F200mA/250V).
