See Table 4 indicated for information about the terminals.
2.4 Terminals
Table 4. Terminals
Description
Terminal
Return terminal for all measurements.
(Receiving the black test lead or the “com”
plug of the special multi-function socket)
Input for voltage, resistance, frequency,
diode and continuity measurements.
(Receiving the red test lead)
Input for capacitance, Temperature, hFE
and 0.001mA to 200mA current
measurements. (Receiving the red test
lead or the “+” plug of the special
multi-function socket)
Input for 10A current measurements.
(Receiving the red test lead)
Delivered with the multimeter:
2.5 Accessories
One piece
• User's manual
One piece
One piece
• Test leads
• Special Multi-function socket
3. Function Description
3.1 General Functions
3.1.1 Misconnection Alarm
The input jacks of the meter are equipped with sound
and light alarms against misconnection of test leads.
COM
VΩHz
°C mA
hFE
10A
1. At V Ω、 Hz ranges:
1) The red lights at the “V” and “COM” jacks will be
off after the test leads are plugged in.
2) The buzzer will sound upon misconnection of the
test leads in the “mA” or “10A” jacks to warn the
user. At the same time, the lights at the “V” and
“COM” jacks will flash to remind the user to plug
in the test leads there.
2. At mA, hFE, ranges:
The red lights at the “mA” and “COM” jacks will
be off after the test leads are plugged in.
The buzzer will sound upon misconnection of
the test leads in the “V” or “10A” jacks to warn the
user. At the same time, the red lights at the “mA”
and “COM” jacks will flash to remind the user to
plug in the test leads there.
3. At 10A range:
1) The red lights at the “10A” and “COM” jacks will be
off after the test leads are plugged in.
2) The buzzer will sound upon misconnection of the
test leads in the “V” or “mA” jacks to warn the user.
At the same time, the lights at the “10A” and
“COM” jacks will
、 、 、
