Master Chef 280 Barbecue - Heat Shield and Electrode Wire Installation; Top Lid Hinge and Handle Assembly; Top Lid Assembly to Burner Box

10 11
ASSEMBLY INSTRUCTIONS
12
13
14
ASSEMBLY INSTRUCTIONS
10
11
Assemble the heat shield (BG) to the inside of the
left burner box support (DB), as shown.
Attach the burner electrode wire (BF2) to the
igniter (CC).
Assemble the upper hinge (AC) to the top lid as-
sembly (AA).
Assemble the top lid handle (AB) to the top lid
assembly (AA).
To assemble the top lid assembly (AA) to the
burner box assembly (BA), position the upper
hinges (AC) in between the lower hinges (BB),
position hardware and lock into place using the
hitch pins.
YOU WILL NEED:
6 7
X 2 X 2
YOU WILL NEED:
2
X 4
YOU WILL NEED:
YOU WILL NEED:
8
11
10
12
X 6
X 2
X 2
X 2
3
X 4
8
X 4
DB
BG
DB
BG
AA
AC
AC
AA
AA
AC
AC
BB
BB
BF2
CC
AC
BB
10
8
8
8
AB
CAUTION: SHARP EDGES,
WEAR SAFETY GLOVES DURING
ASSEMBLY
