ASSEMBLY INSTRUCTIONS
10
e. Position the infrared grease tray (DK) onto the
infrared grease tray rails (DJ).
c. Use the side burner Venturi clip (#20) to
connect the infrared side burner (DD) to the
side burner valve (CC).
d. Position the side burner cooking grate (DG)
onto the infrared support frame (DC).
YOU WILL NEED:
20
X 1
F
G
DG
DC
E
20
View from underneath left side shelf
View from the back, left side
DD
DK
DJ
CC
