Master Forge GBT13039L User Manual

11
Lowes.com/masterforge
®
ASSEMBLY INSTRUCTIONS
9. Attach the lid (B) to the bottom bowl (K) using two
5 x 32 mm pins (LL) and two 1.4 x 30 mm cotter
pins (MM).
Hardware Used
LL
5 x 32 mm Pin x 2
MM
1.4 x 30 mm Cotter
Pin
x 2
9
10. Insert the heat plate (D) and then the cooking grid
(C) into the bottom bowl (K).
11. Slide the grease tray (S) into the bottom
bowl (K).
10
11

Master Forge GBT13039L Specifications

General

Brand	Master Forge
Model	GBT13039L
Category	Grill
Language	English
