Master Forge MFJ576PNC - Door and Brace Installation

8
ASSEMBLY INSTRUCTIONS
Lowes.com/masterforge
1
2
AA
9
W
S
AA
T
8
T
O
V
7
7. Attach upper door brace (T) to the left cart
assembly (V) and the right cart assembly (O).
8. Secure upper door brace (T) using four M6x12
bolts (AA).
9. Attach ash tray handle (S) to left door assembly
(W) using two M6x12 bolts (AA). Repeat for
right door assembly (R).
Hardware Used
M6x12 Bolt
x 4
AA
Hardware Used
M6x12 Bolt
x 4
AA
