11
STEP 10:
Attach Side Shelf
Brackets
Hardware Needed:
(8) M6x12 bolts
STEP 11:
Attach Side Shelf
Hardware Needed:
(4) M5x12 bolts
Side Shelf
Left Bracket
Side Shelf
Right Bracket
Repeat steps 10 and 11
for attaching the other
side table.
M5x12 bolt
M5x12 bolt
(4) M6x12 bolts
FOR YOUR SAFETY, FOLLOW ALL SAFE GUARDS AND INSTRUCTIONS.
ASSEMBLY OF YOUR GRILL IS NOW COMPLETE.
Assembly
A
