• BEFORE ASSEMBLY READ ALL INSTRUCTIONS CAREFULLY.
• Assemble on a clean flat surface.
• Tools needed: Adjustable wrench or pliers, Phillips head screwdriver
• Approximate assembly time: 20 minute
• Actual product may differ from picture shown.
• It is possible that some assembly steps have been completed in the factory.
Hardware List
Qty Description
18 M6 x 12 Combo Truss Head Bolts, Black Nickel Plated
2 M5 x 17 Shoulder Bolts, Black Nickel Plated
4 M5 x 12 Shoulder Bolts, Black Nickel Plated
6 M5 x 10 Combo Truss Head Bolts, Black Nickel Plated
2 M5 Nuts
2 M6 x 20 Combo Truss Head Bolts, Black Nickel Plated
6 Spring Washers
Hardware Pack
D
C
B
E
A
F
G
