SAVE THESE INSTRUCTIONS
DO NOT RETURN TO RETAILER for assembly assistance, missing or damaged parts. Please
contact MASTERBUILT customer service at 1-800-489-1581 or support.masterbuilt.com.
Please have the model number and serial number available. These numbers are located
on the silver rating label on the smoker.
STOP
Parts List
NO QTY DESCRIPTION
1 2 Side Shelf Left Bracket
2 2 Side Shelf
3 2 Side Shelf Right Bracket
4 1 Warming Rack
5 1 Heat Indicator
6 1 Lid Handle
7 1 Lid Decorative Plate
8 2 Cooking Grid
9 1 Wood Chip Box Tent
10 1 Wood Chip Box Lid
11 1 Wood Chip Box
12 1 Wood Chip Box Front Panel Assembly
NO QTY DESCRIPTION
13 1 Wood Chip Box Handle
14 2 Side Supporting Leg
15 2 Heat Tent
16 1 Grease Tray Handle
17 1 Grease Tray
18 1 Rear Supporting Leg
19 1 Wood Chip Box Left Rail
20 1 Wood Chip Box Right Rail
21 1 Grill Lid and Firebox Assembly
22 1 Wood Chip Box Lock
23 1 Hose, Valve and Regulator (preassembled)
8
1
1
2
2
3
3
5
4
6
7
8
9 10
12
11
14
13
1515
16
17
18
20
19
22
21
23
