The working voltage of the battery will
be displayed on the LCD so that the
quality of the battery can be judged.
BATTERY
RANGE DESCRIPTION TEST CURRENT
1.5 V
9 V
12 V
about 20 mA
about 5 mA
about 4 mA
DIODE AND CONTINUITY TEST
RANGE DESCRIPTION TEST CONDITION
The approx. forward
voltage drop of the
diode is shown on the
display.
Open Circuit Voltage:
about 2.8 V
Test Current: about
1 mA
The built-in buzzer will
sound if the resistance
is less than about 30 Ω.
The buzzer may or may
not sound if the
resistance is between
30 Ω and 150 Ω.
The buzzer will not
sound if the resistance
is more than 150 Ω.
Open Circuit Voltage:
about 2.8 V
model no. 052-0060-2 | contact us 1-800-689-9928
11
TECHNICAL SPECIFICATIONS
