When the symbol " " appears on the display, it means that the
battery is low and must be replaced immediately.
To replace battery, remove the screw on the battery cover and
remove the battery cover. Replace the exhausted battery with a new
one of the same type. Reinstall the battery cover and the screw.
Fuse rarely needs to be replaced and is blown almost always as a
result of operator's error. To replace fuse, remove the screws on the
back cover and move the back cover aside gently. Replace the blown
fuse with a new one of the same ratings. Reinstall the back cover and
the screws.
BATTERY AND FUSE REPLACEMENT
This meter uses two fuses:
250 mA/300 V FAST fuse, Ø5×20mm
10 A/300 V FAST fuse, Ø5×20mm
F 1:
F 2:
Manual: 1 piece
Test Lead: 1 pair
ACCESSORIES
18
MAINTENANCE
