Battery Test
Connect the black test lead to the "COM" terminal and the red
test lead to the "VΩmA" terminal.
According to the rated voltage of the battery to be tested, set the
range switch to the corresponding BATT range position.
Connect the test leads to the two terminals of the battery to be
measured.
Read the working voltage of the battery on the display.
1.
2.
3.
4.
Connect the red test lead to the anode of the diode to be tested
and the black test lead to the cathode of the diode.
The display will show the approximate forward voltage drop of
the diode. If the connection is reversed, "1" will be shown on
the display.
3.
4.
16
OPERATING INSTRUCTIONS
