NOTE:
Set the range switch to desired range position.
Turn off power to the circuit you want to measure. Then
discharge all capacitors of the circuit.
Break the circuit path to be measured, and connect the test
leads in series with the circuit.
Turn on power to the circuit.
Read the reading on the display. The polarity of the red
test lead connection will be indicated as well.
2.
3.
4.
5.
6.
Measuring Resistance
Connect the black test lead to the "COM" terminal and the red
test lead to the "VΩmA" terminal.
Set the range switch to desired Ω range position.
Connect the test leads across the object to be measured.
Read the reading on the display.
1.
2.
3.
4.
For measurements > 1000 kΩ, the meter may take a
few seconds to stabilize reading. This is normal for high
resistance measurements.
1.
14
OPERATING INSTRUCTIONS
NOTE:
If the magnitude of the current to be measured is not known
beforehand, set the range switch to the highest range first
and then reduce it range by range until satisfactory
resolution is obtained.
