3. Function / Range Switch
Used to select the desired function and range as well as to turn
on or off the meter.
To preserve battery life, set this switch to the "OFF" position
when not using the meter.
6. "COM" Terminal
Plug-in connector for the black test lead.
4. "10A" Terminal
Plug-in connector for the red test lead for current (200 mA – 10 A)
measurements.
5. "VΩmA" Terminal
Plug-in connector for the red test lead for all measurements
except current measurements 200 mA.
7
INTRODUCTION
model no. 052-0060-2 | contact us 1-800-689-9928
