INSTALLING ACCESSORIES – cont’d
NOTES:
a) Check to make sure the convex curve
of the washer (9) is facing the head of
the screw.
b) Make sure the alignment holes in the
blade or sanding pad are still mated
with the alignment pins in the
accessory holder.
5. Firmly tighten the screw with the 5 mm
hex key.
NOTE: Check to make sure the holes in
the blade are still mated with the alignment
pins on the accessory holder after the
screw is fully tightened.
INSTALLING SANDPAPER
1. Install the hook & loop sanding pad (1)
onto the tool (Fig. 3).
2. Firmly press the sandpaper (2) onto
the hook & loop pad.
NOTES:
a) Place the sandpaper so the holes in the
sandpaper line up with the matching holes
in the hook & loop pad.
b) Press the sandpaper firmly onto the
hook & loop pad.
3. To remove the sandpaper, simply peel
the sandpaper way from the hook &
loop pad (Fig. 4).
