USING THE SCRAPER BLADE
1. Install the scraper blade on the multi-
crafter as outlined on Pages 12 & 13,
Fig. 1 & 2.
2. Set the speed control wheel to #4 and
turn the switch ON.
When using the scraper blade to scrape
old finishes or glue from a workpiece,
place the under side of the blade flat on
the workpiece surface and then lift upward
on the rear of the tool to allow the blade to
form a very slight angle with the workpiece
surface. Feed the blade slowly into the
material that is to be removed. Do not
force the tool as slower travel speeds will
produce better cutting action and reduce
the risk of gouging the workpiece.
When using the scraper blade to cut
carpet, place a scrap workpiece under the
carpet where the cut is being made. Set
the speed to “MAX”, turn the tool so the
scraper blade is at right angles
(perpendicular) to the carpet and then feed
the blade into the carpet.
GENERAL
WARNING: When servicing, use
only identical replacement parts. The
use of any other part may create a
hazard or cause product damage.
DO NOT use solvents when cleaning
plastic parts. Plastics are susceptible to
damage from various types of commercial
solvents and may be damaged by their
use. Use a clean cloth to remove dirt, dust,
oil, grease etc.
WARNING: Do not allow brake
fluids, gasoline, petroleum-based
products, penetrating oils, etc. to come
into contact with plastic parts. They
contain chemicals that can damage,
weaken or destroy plastic.
DO NOT abuse power tools. Abusive
practices can damage the tool and the
workpiece.
WARNING: DO NOT attempt to
modify tools or create accessories. Any
such alteration or modification is
misuse and could result in a hazardous
condition leading to possible serious
injury. It will also void the warranty.
LUBRICATION
All of the bearings in this tool are
lubricated with a sufficient amount of high-
grade lubricant for the life of the unit under
normal conditions. Therefore, no further
lubrication is required.
