MasterCraft 054-1266-4 User Manual

23
WARNING: When servicing, use only Mastercraft
®
replacement parts. The use of
any other parts may create a safety hazard or cause damage to the multi-crafter.
Any attempt to repair or replace electrical parts on this multi-crafter may create a safety
hazard unless repairs are performed by a qualified technician. For more information, call
the Toll-free Helpline, at 1-800-689-9928.
Always order by PART NUMBER, not by key number.
Key #
Part #
Part Name
Quantity
1
1190030008
Power cord
1
2
4030010125
Screw ST3.9X35
1
3
3140010032
Cord guard
1
4
6140020006
Hex key
1
5
1061150016
Switch
1
6
4030010106
Screw ST3.9X19
2
7
3150160126
Switch support
1
8
4030010074
Screw ST3.9X14
3
9
4030010114
Screw ST3.9X25
5
10
3150160127
PCB support
1
11
3011210002
Right handle
1
12
3120110040
Switch lever
1
13
3120010050
Switch lever knob
1
14
3150020004
Cord clamp
1
15
1130010137
PCB
1
16
3011210002
Left handle
1
17
3011210002
Motor housing
1
18
1020210003
Stator
1
19
3150050047
Baffle
1
20
4100050005
E ring 5
1
PARTS LIST
!
