ON/OFF SWITCH
1. To turn the tool ON, slide the ON/OFF
switch (1) toward the front of the tool
(Fig. 5).
2. To turn the tool OFF, slide the
ON/OFF switch toward the rear of the
tool.
SPEED CONTROL WHEEL
The speed of the tool can be adjusted to
run the tool at speeds varying between
10,000 OPM and 18,500 OPM by rotating
the speed control wheel (1) located toward
the rear of the tool housing (Fig. 6).
1. To increase the speed, rotate the
speed control wheel toward the left of
the tool.
2. To decrease the speed, rotate the
speed control wheel toward the right
of the tool.
NOTE: Speed #1 is the lowest speed.
“MAX” is the highest speed.
The optimal speed setting will vary
depending upon the type of accessory
being used, the surface being worked and
the complexity of the project. For general
recommendations, see the chart on the
following page.
