INSTALLING SCREWDRIVER BITS – cont’d
NOTE: Make sure the screwdriver bit is
fully inserted into the magnetic bit holder
until it is held in place by the magnet.
FORWARD/REVERSE SWITCH
The forward/reverse switch (1) is
conveniently mounted above the trigger
switch (Fig. 13). To make the cordless
screwdriver rotate clockwise for drilling or
for driving screws, push the
forward/reverse switch to the left. To make
the cordless screwdriver rotate counter
clockwise for removing screws, push the
forward/reverse switch to the right.
NOTES:
a) Never change the position of the
forward/reverse switch while the collet is
turning.
b) The trigger switch will NOT function with
the forward/reverse switch in the middle
position.
VARIABLE-SPEED TRIGGER SWITCH
This cordless screwdriver is equipped with
a variable-speed ON/OFF trigger switch.
1. To start the screwdriver, gently
squeeze the trigger switch (2)
(Fig. 14).
NOTE: The cordless screwdriver will turn
at its slowest speed when the trigger
switch is squeezed lightly. The cordless
screwdriver will turn at its fastest speed
when the trigger switch is squeezed firmly.
2. To stop the cordless screwdriver,
release the trigger switch.
