CHANGING THE DRIVE BELT – cont’d
9. Place the belt on the edge of the small
pulley (5).
NOTE: Make sure the lugs on the belt
engage the matching grooves in the small
pulley.
10. Press downward on the belt
approximately 1” (2.5 cm) away from
the small pulley (4).
11. Rotate the pulley while pressing down
on the belt, moving your finger toward
the small pulley.
12. Repeat steps #10 & #11 until the belt
is fully installed on the small pulley.
NOTE: Once the belt is fully installed on
the small pulley, rotate the pulleys and
check to make sure the belt is fully
engaged in ALL the grooves in BOTH the
large and small pulleys. If the belt is not
engaging all the grooves, it will damage
the tool and the belt will be ruined.
WARNING: Do not start the tool
before the belt cover is installed. Serious
injury may result.
13. Replace the belt cover. Do not over
tighten the screws.
14. Turn the switch ON and make sure
the belt is turning and tracking
properly without any unusual vibration.
Recheck the belt installation if you find
any unusual vibration.
