MasterCraft 62-3510-0

Repair Parts 6
1
8
2
3
4
6
5
7
9
Key Part No.
No. Description Used 62-3510-0
1 Motor 1 *
2 Volute (Pump Body) 1 S1-31B
3 Impeller 1 PS5-21P
4 Base Plate 1 PS4-17P
5 Float 1 FT0013-63
6 Float Rod Guide 1 RP0005249
7 Float Rod 1 RP005168S
8 Switch 1 †
9 Float Stop 2 RP0005248
Model 62-3510-0
* If the motor fails, replace the entire pump. † Select switch model number below.
Switch FP0020
Switch FP0018-7D
