6.3.4 Configuration
Below parameters can be changed via the MasterBus network by means of a remote control panel or by means of an interface
connected to a PC with MasterAdjust software. See applicable user’s manuals for details.
Value Meaning Factory setting Adjustable. range
General
Language Language displayed on a MasterBus monitoring device English See specifications
Product name Name of this device. This name will be recognized by
all devices connected to the MasterBus.
CHG CM+type* 0-12 chars
Output 1 Name of output 1 in the MasterBus network House bank 12 characters max
Output 2 Name of output 2 in the MasterBus network Output 2 12 characters max
Output 3 Name of output 3 in the MasterBus network Output 3 12 characters max
Factory settings Button to reset the ChargeMaster to factory settings
Charge current
AC load Select the method to reduce the AC input power Auto Auto, MPC, manual
Maximum current Set the maximum charging current allowed Model depend. Model dependent
System System
System behaviour Set the use mode. The ChargeMaster can be
synchronized with other MasterBus chargers.
System
behaviour
Set the use mode. The
ChargeMaster can be
synchronized with other
MasterBus chargers.
MasterShunt Select the MasterShunt that provides the
ChargeMaster with battery information.
MasterShunt Select the MasterShunt
that provides the
ChargeMaster with battery
information.
Bulk
Bulk voltage Bulk voltage 14.40/28.80V 0-15.50/0-31.00V
Max. bulk timer Maximum bulk timer 8h 0-24h
Min bulk timer Minimum bulk timer 120sec 0-240sec
Start bulk timer Start bulk timer 13.25/26.50V (read only)
Absorption
Abs. voltage Absorption voltage 14.25/28.50V 0-15.50/0-31.00V
Max absorption Maximum absorption timer 4h 0-24h
Min absorption Minimum absorption timer 15min 0-240min
Return amps Return amps (% of maximum charge current) 6% 0-50%
Return amps tim Return amps timer 30sec 0-240sec.
Float settings
Float voltage Float voltage 13.25/26.50V 0-15.50/0-31.00V
Forced float vo. Forced float voltage
(Constant voltage charging)
13.25/26.50V 0-15.50/0-31.00V
Return to bulk Return to bulk voltage 12.80/25.60V 0-15.50/0-31.00V
Return to bulk Return to bulk time delay 30sec 0-240sec
Alarms
DC high on Alarm DC High on 16.00/32.00V 0-16.00V0-32.00V
DC high off Alarm DC High off 15.00/30.00V 0-16.00V0-32.00V
DC low on Alarm DC low on 10.00/20.00V 0-16.00/0-32.00V
DC low off Alarm DC low off 11.00/22.00V 0-16.00/0-32.00V
Alarm delay Alarm delay time 30sec 0-240sec
Traction
Traction Bulk v Traction bulk voltage +300/+600mV (read only)
Traction Absorpt Traction absorption voltage +300/+600mV (read only)
Traction absorpt Traction absorption timer 8 hrs (read only)
Equalization
Equalize voltage Equalize voltage float +2.25/+4.50V (read only)
Max equalize tim Max equalize timer 480 min (read only)
DIP-switches
Battery type Setting for AGM/Gel batteries.
Off = Wet battery, On = AGM/Gel
Off Off, On**
Charge algorithm 12V/24V power supply allowed. Off=no, On=yes Off Off, On**
Display mode Display off saves batteries. Off=no, On=yes Off Off, On**
