TROUBLE SHOOTING
EN / Chargemaster1 12/35-3, 12/50-3, 24/20-3 & 24/30-3 / August 2009 21
7 TROUBLE SHOOTING
If you cannot solve a problem with the aid of this chapter, contact your local Mastervolt Service Centre. See
www.mastervolt.com. Make sure you have the following information present if you have to contact your local Mastervolt
Service Center to solve a problem:
Article and serial number (See section 1.4)
Software version (See section 6.3.3)
7.1 FAULT FINDING TABLE
Malfunction Possible cause What to do
No AC-input Check AC wiring, check remote control panel.
AC-input voltage too low (< 90VAC) Check input voltage, check generator.
No output voltage
and/or current
AC input frequency out of range Check input voltage, check generator.
Load that is connected to the batteries is
larger than charger can supply.
Reduce load taken from the batteries. Output voltage too low,
charger supplies
maximum current
Batteries not 100% charged Measure battery voltage. After some time this will
be higher.
Batteries almost fully charged Nothing, this is normal when the battery is almost
fully charged.
High ambient temperature Nothing; if ambient temperature is more than the
setting limit the charge current is automatically
reduced.
Charge current too low
Low AC input voltage. At lower AC input
voltages the charge current is reduced.
See figure 15.
Check AC-input voltage.
Charge current too low See “Charge current too low” in this table.
Current to load is too high Reduce load taken from the batteries.
Charge time too short Use a battery charger with higher capacity.
Battery temperature too low Use the battery temperature sensor.
Batteries not fully
charged
Defective or old battery Check battery and replace if necessary.
Batteries are
discharged too fast
Battery capacity reduced due to wastage or
sulphation, stagnation
Charge and recharge a few times, this might help.
Check battery and replace if necessary.
Defective battery (short circuit in cell) Check battery and replace if necessary.
Battery temperature too high Use the battery temperature sensor.
Batteries are too warm,
gassing
Charge voltage too high Check settings (see section 6.3.4).
Display is switched off. Switch on display, refer to display manual. No MasterView display
function.
Error in the wiring. Check the MasterBus cables.
Error in the MasterBus wiring. Check the MasterBus cables.
No terminating device placed at the ends of
the network.
MasterBus needs a terminating device on both
ends of the network. Check if connected (see
section 6.2).
Slow or no MasterBus
communication.
MasterBus network is configured as a ring
network.
Ring networks are not allowed. Check the
connections of the network (see section 6.2).
MasterView Easy panel
connected to the
ChargeMaster, no
communication.
The Easy panel has been switched off or
MasterBus is not working correctly.
Check MasterBus wiring, a terminator should be
placed on both ends of the MasterBus network.
