6.3.4 Level 3: Configuration
Below parameters can be changed via the MasterBus network by means of a remote control panel or by means of an interface
connected to a PC with MasterAdjust software. See applicable user’s manuals for details.
Value Meaning Factory setting Adjustable. range
Language
Language that is displayed on a monitoring device
connected to the MasterBus
English English
Bulk settings
Bulk voltage Bulk voltage 14.40/28.80V 0-15.50/0-31.00V
Max. bulk timer Maximum bulk timer 8h 0-24h
Min bulk timer Minimum bulk timer 120sec 0-240sec
Start bulk timer Start bulk timer 13.25/26.50V (read only)
Absorption settings
Abs. voltage Absorption voltage 14.40/28.80V 0-15.50/0-31.00V
Max absorption Maximum absorption timer 4h 0-24h
Min absorption Minimum absorption timer 15min 0-240min
Return amps Return amps (% of maximum charge current) 6% 0-50%
Return amps tim Return amps timer 30sec 0-240sec.
Float settings
Float voltage Float voltage 13.25/26.50V 0-15.50/0-31.00V
Forced float vo.
Forced float voltage
(Constant voltage charging)
13.25/26.50V 0-15.50/0-31.00V
Return to bulk Return to bulk voltage 13.25/26.50V 0-15.50/0-31.00V
Return to bulk Return to bulk time delay 30sec 0-240sec
Max Charge curr Maximum charge current 100% 0-100%
Alarm setpoints
DC high on Alarm DC High on 16.00/32.00V 0-16.00V0-32.00V
DC high off Alarm DC High off 15.00/30.00V 0-16.00V0-32.00V
DC low on Alarm DC low on 10.00/20.00V 0-16.00/0-32.00V
DC low off Alarm DC low off 11.00/22.00V 0-16.00/0-32.00V
Alarm delay Alarm delay time 30sec 0-240sec
Device settings
Product name on.
Name of this device. This name will be recognized by all
devices connected to the MasterBus
CHG CM+type* 0-12 chars
Traction settings
Traction Bulk v Traction bulk voltage +300/+600mV (read only)
Traction Absorpt Traction absorption voltage +300/+600mV (read only)
Traction absorpt Traction absorption timer 480 min (read only)
Equalize settingsTraction settings
Equalize voltage Equalize voltage float +2.25/+4.50V (read only)
Max equalize tim Max equalize timer 8h (read only)
Fixed settings
Temperature com Temperature compensation for charge voltage
-30mV/°C
-60mV/°C
(read only)
Max allowed upp Maximum allowed upper temperature +300/+600mV (read only)
Max allowed low Maximum allowed lower temperature 480 min (read only)
Max voltage com
Maximum voltage compensation for temperature
compensated charging,
+0.3/+0.6V (read only)
AGM / GEL floa AGM / GEL float voltage setting +550/+1100mV (read only)
Hardware settings
Gel / AGM DIP-switch 1: Battery type (see section 5.1.1) (read only)
Force float DIP switch 2: Charge algorithm (see section 5.1.2) (read only)
Equalize DIP switch 4: Equalize mode (see section 5.1.4) (read only)
