5.2.2 Settings menu for models 24/40-3, 24/60-3, 24/80-3 and 24/100-3
Display
Stage
Display
Text
Setting min default max unit resolution
BULK BULK VOLT Bulk voltage 0.00 28.80 31.00 V 0.05
BULK MAX TMR Maximum bulk timer 0 8h 24h h / min 1min
BULK MIN TMR Minimum bulk timer 0 120sec 240sec sec 1sec
ABS ABS VOLT Absorption voltage 0.00 28.50 31.00 V 0.05
ABS MAX TMR Max. absorption timer 0 4h 24h h / min 1min
ABS MIN TMR Min absorption timer 0 15min 240min h / min 1min
ABS RET AMP
Return amps (% of maximum
charge current)
0% 6% 50% % 1%
ABS RET AMP Return amps timer 0 30sec 240sec sec 1sec
FLOAT FLT VOLT Float voltage 0.00 26.50 31.00 V 0.05
FLOAT CONST FLT
Forced float voltage
(Constant voltage charging)
0.00
26.50 31.00
V 0.05
RET BULK Return to bulk voltage 0.00 25.60 31.00 V 0.05
RET BULK Return to bulk time delay 0 30sec 240sec sec 1sec
MAX CURR Maximum charge current 0 nominal nominal A 1A
ALM DEL Alarm delay time 0 30sec 240 sec 1sec
HIGH DCON Alarm DC High on 0.00 32.00 32.00 V 0.05
HIGH DCOF Alarm DC High off 0.00 30.00 32.00 V 0.05
LOW DCON Alarm DC low on 0.00 20.00 32.00 V 0.05
LOW DCOF Alarm DC low off 0.00 22.00 32.00 V 0.05
RES FACT Reset to factory settings NO YES
