T
ECHNICAL DATA
31
8.2 SPECIFICATIONS 24V MODELS
Model 24/40-3 24/60-3 24/80-3 24/100-3
Article no. 44020400 44020600 44020800 44021000
GENERAL
Nominal input voltage**: 120/230V 120/230V 120/230V 120/230V
Nominal input frequency: 50/60Hz 50/60Hz 50/60Hz 50/60Hz
Full load consumption 1400VA 2000VA 2700VA 3375VA
Max. AC input current (@ 230VAC) 8A 10A 13A 16A
Max. AC input current (@ 120VAC) 16A 20A 26A 32A
Nominal output voltage: 24V 24V 24V 24V
Total charge current*: 40A at 28.8V 60A at 28.8V 80A at 28.8V 100A at 28.8V
Number of battery outlets: 3 3 3 3
Max. current second output: 10A +/- 10% 10A +/- 10% 10A +/- 10% 10A +/- 10%
Max. current third output: 10A +/- 10% 10A +/- 10% 10A +/- 10% 10A +/- 10%
Charge characteristic*: IUoUo, automatic, three step plus
Charge voltage Bulk*: 28.8V 28.8V 28.8V 28.8V
Charge voltage Absorption*: 28.5V 28.5V 28.5V 28.5V
Charge voltage Float*; 26.5V 26.5V 26.5V 26.5V
Max. absorption and max. bulk timer*: 8 hours (start max. bulk timer at 26.5V)
Minimum absorption time*: 15 min. 15 min. 15 min. 15 min.
Battery type settings*: Open lead / gel / traction / AGM / spiral (adjustable by means of DIP-switch)
Dimensions (mm): 362x277x150 362x277x150 432x277x150 432x277x150
Dimensions (inch): 14.3x11.0x5.9 14.3x11.0x5.9 17.0x11.0x5.9 17.0x11.0x5.9
Weight: <7kg (<16Lbs) <7kg (<16Lbs) <8kg (<18Lbs) <8kg (<18Lbs)
Recommended battery capacity: 100-500Ah 150-750Ah 200-1000Ah 200-1000Ah
Power factor regulations ≤ 0,98 ≤ 0,98 ≤ 0,98 ≤ 0,98
Temperature compensation Battery temperature sensor and cable included.
Voltage compensation Yes, by means of automatic compensation.
DC consumption <5mA <5mA <5mA <5mA
Temperature range –25°C (–13°F) to 60°C (140°F) derating 3%/°C (2%/°F) above 40°C (104°F),
90% derating under 0°C (32°F)
Cooling Vario fan and natural cooling to ensure optimized cooling when unit stored in
corners etc.
Sound level <52dBA / 1m
Protection degree IP23 IP23 IP23 IP23
Approvals Fully CE and E-marking according to automotive directive 95/54/EG / UL pending
MasterBus connectivity Yes Yes Yes Yes
Powering capabilities for MasterBus Yes, when the charger is switched on, it can power up to three non-powering
devices.
* Adjustable, see chapter 5 for settings
** See also figure 9
Specifications are subject to change without prior notice.
